GD-66 High Precision Mill Cutter Grinder Resharpener
B2B
Product information
- Year: 2005
Description
Features
Having open type structure helps to expand operation space and enlarge grinding range; this machine can grind milling cutter, reamer relief angle and cutting edge, with changing of differen attachments also can grind ball end mill and screw tap guide cutting edge. The main part of sharpener is made of excellent aluminium, with such features as light weight, vibration absorption, corrosion resistance, etc. Adopts internationally advanced pneumatic suspension technology, flexible spindle rotation after pressurization, that minimize friction and greatly increase service life.
Specifications
GD-66
Application
1,2,3,4,5,6flutes HSSend mill, carbide end mill
Capacity(shank dia xblade dia. xlength)
50*175*200mm
Table cross travel (X axis)
115mm
Table longitudinal travel (Y AXIS)
60mm
Table in-feed graduation:
0.02mm
Adiustment for wheel head:
+35°~-5°
Air bearing swivel
360°
Dia. Of grinding wheel
125*52*32mm
Air consumption
more than 0.63MP
Motor
220V/0.25KW/50Hz/2800rmp
Packing size LxWxH
77X70X60CM
Gross weight
120kg
